Cov Ntsiab Lus Yooj Yim
|
Kem hauv qhov taub |
N-hom 210mm ib nrab txiav |
|
Qho hnyav |
38.7kg ± 3% |
|
Qho loj dav |
2384 ± 2mmx1303 ± 2mm × 35/30 hli |
|
Iav Hauv Pem Hauv Ntej |
2. {{0 hli (0. 08 nti), siab kis, A co coated cua sov zog zog iav |
|
Sab nraub qaum |
2. {{{0 mm (0. 08 nti), cua sov ntxiv dag zog Iav (Daim phiaj dawb paug iav) |
|
Tsis muaj ntawm cov hlwb |
132(6×11+6×11) |
|
Lub thawv hlws ris |
IP ntau dua los yog sib npaug rau 68,3dies |
|
Cable & Connector |
4 hli, evo2 lossis evo2 sib xws |
|
Modules ib pallet |
31 / 36Pieces |
|
Modules ib 40HQ |
558pieces |
Daim Duab Neeg Kho Tshuab
Cim: Customized ncej xim thiab cable ntev muaj thaum thov
Cov khoom lag luam zoo
1. Cov Khoom Siv Hluav Taws Xob Loj:Jingsun lub 750 Watt Hnub Ci vaj huam sib luag siv cov khoom ua haujlwm siab ntau-busbar n-hom hluav taws kub ntau dua li cov khoom siv hluav taws xob zoo dua li cov khoom siv hnub ci ntau dua. Qhov no txhais tau tias cov vaj huam sib txuas tuaj yeem tsim hluav taws xob ntau ntxiv, ua rau lawv muaj txiaj ntsig zoo dua ntawm lub zog txuas ntxiv.
2. Cov khoom siv kub zoo dua:Ib nrab-cell configuration ntawm Jingsun cov modules muaj kev ua tau zoo dua kub dua lwm cov panels. Qhov no txhais tau tias lawv tuaj yeem tsim hluav taws xob ntau dua hauv cov xwm txheej kub, ua rau lawv xaiv zoo rau thaj chaw muaj qhov kub.
3. Txo cov nyhuv ntxig:Jingsun lub hnub ci ntsa iab yog tsim los muaj cov nyhuv nyoos ntawm lub zog loj. Qhov no txhais tau tias txawm hais tias ib feem ntawm lub vaj huam sib luag yog duab ntxoo, nws tseem yuav tsim kom muaj hluav taws xob zoo. Qhov no ua rau lawv zoo tagnrho rau thaj chaw nroog uas shading los ntawm cov tuam tsev thiab lwm yam kev teeb tsa muaj ntau.
4. Txo txoj kev pheej hmoo ntawm cov chaw kub:Ib nrab-cell configuration ntawm Jingsun cov modules txo qhov kev pheej hmoo ntawm kub me ntsis, uas tuaj yeem ua kev puas tsuaj hnub ci thiab txo lawv cov kev ua kom muaj zog. Qhov no txhais tau tias Jingsun lub hnub ci ntsa iab yog cov txhim khu kev qha ntau dua thiab ntev-ntev tshaj li cov pa hluav taws xob.
5. Txhim kho kev ua siab ntev rau cov khoom siv tshuab:Jingsun lub hnub ci ntsa iab yog tsim los ua kom muaj kev ntxhov siab ntau dua uas lawv tuaj yeem tiv kev ntxhov siab los ntawm cua, thiab lwm qhov chaw ib puag ncig. Qhov no ua rau lawv pom zoo rau cov huab cua muaj huab cua tsis haum, xws li cov kab ke huab cua lossis thaj tsam tau nquag ua rau muaj cua daj cua dub.
Cov Hluav Taws Xob Hluav Taws Xob ntawm SCC
|
Ntaus |
Jam132d -720 n |
Jam132d -725 n |
Jam132d -730 n |
Jam132d -735 n |
Jam132d -740 n |
Jam132d -745 n |
Jam132d -750 n |
|
Ntau zog pmax |
720W |
725W |
730W |
735W |
740W |
745W |
750W |
|
Qhib Circuit Courtage VOC |
46.54V |
46.64V |
46.74V |
46.84V |
46.94V |
47.04V |
47.14V |
|
Qhov siab tshaj hluav taws xob voltage vmp |
40.4V |
40.6V |
40.8V |
41.0V |
41.2V |
41.4V |
41.6V |
|
Luv Circuit Court Voltage ISC |
18.39A |
18.46A |
18.53A |
18.60A |
18.67A |
18.74A |
18.81A |
|
Lub Zog Tshaj Plaws Tam Sim No |
17.82A |
17.86A |
17.89A |
17.93A |
17.96A |
18.00A |
18.03A |
|
Module kev ua haujlwm |
23.2% |
23.3% |
23.5% |
23.7% |
23.8% |
24.0% |
24.1% |
|
Lub Zog Kev Zam |
0~+5W |
||||||
|
Kub Coefficient ntawm ISC (_ ISC) |
{{0 {}}. 042% / degree |
||||||
|
Kub Coefficient ntawm ISC (_ ISC) |
{{0 {}}. 240% / Qib |
||||||
|
Kub coefficient ntawm pmax (_ PMP) |
{{0 {}}. 280% / Qib |
||||||
|
Stc |
Irradiance 1000W / M², Cell Kub 25 Qib, Am1.5g |
||||||
Nco ntsoov: cov ntaub ntawv hluav taws xob hauv phau ntawv teev ua ke no tsis hais txog ib qho module thiab lawv tsis yog qhov kev sib piv ntawm cov qauv sib txawv.
Kev ntsuas kom tsis kam ntawm STC: PMAX ± 3%, VOC ± 2% thiab ISC ± 4%.
Cov yam ntxwv hluav taws xob nrog cov hluav taws xob tsis muaj zog (siv rau 10% irradiance piv)
|
Ntaus |
Jam132d -720 n |
Jam132d -725 n |
Jam132d -730 n |
Jam132d -735 n |
Jam132d -740 n |
Jam132d -745 n |
Jam132d -750 n |
|
Ntau zog pmax |
792W |
798W |
803W |
809W |
814W |
820W |
825W |
|
Qhib Circuit Courtage VOC |
46.84V |
46.99V |
47.14V |
47.29V |
47.44V |
47.59V |
47.74V |
|
Qhov siab tshaj hluav taws xob voltage vmp |
40.71V |
40.87V |
41.03V |
41.19V |
41.35V |
41.51V |
41.67V |
|
Luv Circuit Coalrage ISC (A) |
19.37A |
19.44A |
19.51A |
19.58A |
19.65A |
19.72A |
19.79A |
|
Lub zog siab tshaj plaws tam sim no tus kheej (a) |
19.45A |
19.53A |
19.57A |
19.64A |
19.69A |
19.75A |
19.80A |
|
Xov tooj cua Irradiance (tsheb / pem hauv ntej) 10% |
Fais fab bifaciality: 70 ± 10%. |
||||||
Kev khiav hauj lwm
|
Qhov siab tshaj plaws hluav taws xob voltage |
1500vdc (iec) |
|
Kev khiav hauj lwm kub |
40 degree ~ {+85 degree |
|
Ntau tshaj plaws Series Fuse |
30/35A |
|
Qhov siab kawg li qub lub nra, pem hauv ntej |
5400PA, 1.5 |
|
Qhov siab kawg li qub lub nra, rov qab |
2400pa, 1.5 |
|
Noct |
45 ± 2 degree |
|
Daim Ntawv Thov Chav |
Chav Kawm A |
Cov txheej txheem ntau lawm
Lub Jingsun 750WATT n-hom Bifacial solar vaj huam sib luag yog tsim los siv cov txheej txheem ua tau zoo thiab hloov pauv tau zoo heev. Cov txheej txheem ntau lawm pib nrog kev xaiv cov ntaub ntawv zoo tshaj plaws, suav nrog kev ua yeeb yam zoo tshaj plaws N-hom Silicon hlwb, khob cij iav, thiab txhuas thav ntawv.
Ntim thiab xa khoom
Jingsun 750Watt N-Hom Bifacial solar vaj huam sib luag yog tsim nrog sab saum toj-unch craftsmanship thiab txiav cov kev xaiv ntawm ntug uas ua rau nws xaiv qhov uas xav tau zoo rau cov neeg siv khoom. Txhawm rau kom ntseeg tau tias cov khoom nce mus txog peb cov neeg siv khoom hauv cov xwm txheej zoo tag nrho, peb tau nqis peev thiab peev txheej los tsim cov khoom lag luam thiab lub kaw lus zoo. Peb lub tshuab ntim khoom ua rau muaj kev nthuav dav los tiv thaiv cov vaj huam sib luag los ntawm kev puas tsuaj thaum lub sijhawm thauj khoom. Cov khoom lag luam tau ntim rau hauv ntau txheej ntawm cov khoom tiv thaiv rau cushion tiv thaiv ib qho kev tshee, kev cuam tshuam, lossis kev ntxhov siab uas ua rau muaj kev phom sij.
Peb txoj kev pabcuam kev lag luam yog txhim khu kev qha thiab hloov tau, tsim kom muaj cater cable rau cov neeg siv khoom sib txawv thiab cov neeg siv khoom plig. Txawm hais tias nws yog xa khoom los ntawm hiav txwv, huab cua, lossis thaj av, peb xyuas kom cov khoom tuaj txog ntawm lub hom phiaj nyab xeeb thiab raws sijhawm. Tsis tas li ntawd, peb tau tsim cov chaw ua haujlwm tsim khoom thoob plaws Europe, ua rau peb muab cov kev pabcuam sai thiab yooj yim rau peb cov neeg siv khoom.
Cov FAQ
Q: Dab tsi yog jingsun n-hom 750Watt Hnub Solar Vaj Huam Sib Luag?
Q: Cov txiaj ntsig ntawm Jingsun n-hom 750Watt Hnub ci vaj huam sib luag?
Q: Dab tsi yog lub neej nyob ntawm jingsun n-hom 750Watt Hnub Solar Vaj Huam Sib Luag?
Q: Jingsun N-hom 750Watt Hnub ci vaj huam sib luag siv tau hauv txhua hom hnub ci ntsa iab?
Q: Ua li cas Jingsun N-hom 750Watt Hnub Solar Vaj Huam Sib Luag rau lwm lub hnub ci ci rau kev ua lag luam?
