Khoom Zoo
- Multi-busbar Technology:Lub Longi 415W classic hnub ci vaj huam sib luag nta multi-busbar thev naus laus zis, ua kom lub zog hloov pauv tau zoo dua qub, nce tam sim no ntws, thiab txhim kho kev ua haujlwm hauv cov teeb pom kev tsawg.
- Passivated Emitter Rear Contact (PERC) Technology:Lub vaj huam sib luag tau nruab nrog passivated emitter rear contact (PERC) thev naus laus zis, txhim kho nws cov zis hluav taws xob thiab ua haujlwm ntev ntev.
- Cov ntaub ntawv zoo:Lub Longi 415W classic hnub ci vaj huam sib luag yog ua los ntawm cov khoom zoo thiab ruaj khov, ua kom muaj kev ua haujlwm ntev thiab ua haujlwm rau huab cua hnyav.
- Anti-reflective txheej:Lub vaj huam sib luag los nrog cov txheej tiv thaiv kev cuam tshuam uas txo qhov kev xav, ua kom lub teeb nqus, thiab ua kom muaj zog ntxiv.
- Versatility:Lub Longi 415W classic hnub ci vaj huam sib luag yog ntau yam txaus los siv rau hauv ntau hom kev siv thiab zoo tagnrho rau ob qho tib si hauv tsev thiab kev lag luam hnub ci.
Specifications
Hluav taws xob Parameters ntawm STC
|
Hom Module |
LR5-54HPH-405M |
LR5-54HPH-410M |
LR5-54HPH-415M |
LR5-54HPH-420M |
LR5-54HPH-425M |
|
Rated Maximum Fais Fab (Pmax) |
405W |
410W |
415W |
420W |
425W |
|
Qhib Circuit Court voltage (Voc) |
37.00V |
37.25V |
37.5V |
37.75V |
37.96V |
|
Luv Circuit Court tam sim no (lsc) |
13.83A |
13.88A |
13.94A |
14.01A |
14.08A |
|
Max zog Voltage (Vmp) |
31.00V |
31.25V |
31.49V |
31.73V |
31.94V |
|
Max zog tam sim no (lmp) |
13.07A |
13.12A |
13.18A |
13.24A |
13.31A |
|
Module Efficiency |
20.7% |
21.0% |
21.3% |
21.5% |
21.8% |
|
Hwj chim Tolerance |
0~+5W |
||||
|
Kub Coefficient ntawm lsc ( _lsc) |
+0.050% / degree |
||||
|
Temperature Coefficient of Voc( _Voc) |
-0.265% / degree |
||||
|
Kub Coefficient ntawm Pmax ( _Pmp) |
-0.340% / degree |
||||
|
STC |
Irradiance 100W / m2, cell kub 25 degree, AM1.5G |
||||
Hluav taws xob Parameters ntawm NOCT
|
Hom Module |
LR5-54HTB-410M |
LR5-54HTB-415M |
LR5-54HTB-420M |
LR5-54HTB-425M |
LR5-54HTB-430M |
|
Rated Maximum Fais Fab (Pmax) |
302.7W |
306.5W |
310.2W |
313.9W |
317.7W |
|
Qhib Circuit Court voltage (Voc) |
34.79V |
35.02V |
35.26V |
35.49V |
35.69V |
|
Luv Circuit Court tam sim no (lsc) |
11.18A |
11.22A |
11.27A |
11.32A |
11.38A |
|
Max zog Voltage (Vmp) |
28.80V |
29.03V |
29.25V |
29.47V |
29.67V |
|
Max zog tam sim no (lmp) |
10.52A |
10.56A |
10.60A |
10.65A |
10.71A |
|
NOCT |
AM1.5 800W/㎡ 25 degree 1m/s |
||||
Kev khiav hauj lwm Parameter
|
Maximum System Voltage |
1500V / 1500V DC (IEC) |
|
Ua haujlwm kub |
-40 degree ~ +85 degree |
|
Maximum Series Fuse |
25A |
|
Maximum Static Load, Pem Hauv Ntej |
5400Pa (112lb/ft²) |
|
Maximum Static Load, Rov qab |
2400Pa (50Ib/ft²) |
|
NOCT |
45 ± 2 degree |
|
Hailstone Test |
25 hli Hailstone ntawm qhov ceev ntawm 23m / s |
|
Chav kawm tiv thaiv |
Chav II |
|
Kev ntsuas hluav taws |
UL hom 1 lossis 2IEC Class C |
Kev koom tes hom
- Jingsun txaus siab tshaj tawm kev koom tes nrog cov tuam txhab hnub ci zog thoob ntiaj teb. Los ntawm kev koom tes nrog cov hom no, peb muaj peev xwm muab peb cov neeg siv khoom zoo tshaj plaws hauv hnub ci thev naus laus zis thiab xyuas kom meej tias peb nyob twj ywm nyob rau hauv pem hauv ntej ntawm kev lag luam ceev ceev no.
- Los ntawm cov kev sib koom tes zoo no, peb kuj tseem tuaj yeem nthuav peb txoj kev ncav cuag thiab muab peb cov kev pabcuam rau ntau tus neeg siv khoom. Nrog rau peb cov peev txheej thiab kev txawj ntse, peb ntseeg siab tias Jingsun thiab peb cov tuam txhab koom tes yuav txuas ntxiv ua tus thawj coj hauv kev txhim kho lub hnub ci zog daws teeb meem uas muaj nqi pheej yig thiab siv tau rau txhua tus.
- Yog tias koj xav paub ntxiv txog peb txoj kev koom tes thiab cov kev pabcuam uas peb muab, thov tsis txhob yig tiv tauj peb hnub no. Ua ke, peb tuaj yeem pab txhim kho lub neej yav tom ntej rau peb lub ntiaj teb.
FAQ
Q: Longi 415W Classic Solar Vaj Huam Sib Luag yog dab tsi thiab nws yog dab tsi?
Q: Dab tsi yog qhov ua tau zoo ntawm Longi 415W Classic Solar Vaj Huam Sib Luag?
Q: Dab tsi yog qhov kav ntev ntawm Longi 415W Classic Solar Vaj Huam Sib Luag?
Q: Puas yog Longi 415W Classic Solar Vaj Huam Sib Luag tuaj yeem siv rau hauv cov kab hluav taws xob sab nraud?
Q: Lub sijhawm lav rau Longi 415W Classic Solar Vaj Huam Sib Luag yog dab tsi?
Cim npe nrov: lr5 54hph 415m, Tuam Tshoj lr5 54hph 415m manufacturers, lwm tus neeg, Hoobkas
