Khoom Description
1. Top-notch Quality:Longi 585W Ob Chav Iav Hnub Ci Vaj Huam Sib Luag yog tsim los ntawm cov khoom siv zoo tshaj plaws thiab ua tiav cov kev kuaj xyuas nruj, kom ntseeg tau tias lawv cov txheej txheem tsim khoom yog sab saum toj-ntawm-tus-kab. Qhov no thaum kawg txhais ua cov khoom lag luam ntev dua thiab muaj zog dua, muab cov neeg siv khoom muaj txiaj ntsig ntau dua rau cov nyiaj.
2. Kev siv ntau yam:Lub Longi 585W Ob Chav Iav Hnub Ci Vaj Huam Sib Luag tuaj yeem siv rau hauv ntau hom kev siv, los ntawm cov chaw nyob thiab kev lag luam mus rau cov kab sib chaws. Qhov kev hloov pauv no ua rau nws yog qhov kev xaiv zoo tshaj plaws rau txhua tus neeg tab tom nrhiav kev nqis peev hauv lub hnub ci vaj huam sib luag uas muaj kev ntseeg siab thiab ntau yam.
3. Exceptional Efficiency:Ntawm 22.6%, Longi 585W Ob Chav iav hnub ci vaj huam sib luag boasts ib qho kev ua tau zoo tshaj plaws. Qhov no txhais tau hais tias nws muaj peev xwm hloov tau ntau lub hnub ci rau hauv lub zog siv tau, ua rau muaj zog ntau dua ntawm tus nqi qis.
4. Extended Warranty Coverage:Nrog rau 15- xyoo khoom warranty thiab 30- xyoo fais fab tso zis lav, Longi 585W Ob Chav iav hnub ci vaj huam sib luag yog tsim kom kav ntev. Qhov kev pab cuam ntev ntev no muab cov neeg siv khoom muaj kev thaj yeeb nyab xeeb paub tias lawv cov peev txheej tseem muaj kev tiv thaiv thiab tuaj yeem tiv taus qhov kev sim ntawm lub sijhawm.
5.Outstanding Performance:Tshaj li ntawm 30 xyoo, Longi 585W Ob Chav iav hnub ci vaj huam sib luag yuav tsum tuav lub zog tso tawm ntau dua 86.9%. Qhov no qhia tau hais tias lub vaj huam sib luag tuaj yeem xa cov khoom siv hluav taws xob zoo ib yam thiab txhim khu kev qha, ua rau nws yog qhov kev xaiv zoo tshaj plaws rau kev xav tau lub zog mus sij hawm ntev.
Specifications
Hluav taws xob yam ntxwv ntawm STC
|
Hom Module |
LR5-72HTD-560M |
LR5-72HTD-565M |
LR5-72HTD-570M |
LR5-72HTD-575M |
LR5-72HTD-580M |
LR5-72HTD-585M |
|
Rated Maximum Fais Fab (Pmax) |
560W |
565W |
570W |
575W |
580W |
585W |
|
Qhib Circuit Court voltage (Voc) |
51.70V |
51.85V |
52.00V |
52.15V |
52.30V |
52.45V |
|
Luv Circuit Court tam sim no (lsc) |
13.87A |
13.93A |
14.00A |
14.06A |
14.13A |
14.19A |
|
Max zog Voltage (Vmp) |
43.25V |
43.40V |
43.55V |
43.70V |
43.85V |
44.00V |
|
Max zog tam sim no (lmp) |
12.95A |
13.02A |
13.09A |
13.16A |
13.23A |
13.30A |
|
Module Efficiency |
21.7% |
21.9% |
22.1% |
22.3% |
22.5% |
22.6% |
|
Hwj chim Tolerance |
0~+5W |
|||||
|
Kub Coefficient ntawm lsc ( _lsc) |
+0.050% / degree |
|||||
|
Temperature Coefficient of Voc( _Voc) |
-0.230% / degree |
|||||
|
Kub Coefficient ntawm Pmax ( _Pmp) |
-0.280% / degree |
|||||
|
STC |
Irradiance 1000W / ㎡, cell kub 25 degree, AM1.5G |
|||||
Hluav taws xob yam ntxwv ntawm NOCT
|
Hom Module |
LR5-72HTD-560M |
LR5-72HTD-565M |
LR5-72HTD-570M |
LR5-72HTD-575M |
LR5-72HTD-580M |
LR5-72HTD-585M |
|
Rated Maximum Fais Fab (Pmax) |
418W |
422W |
426W |
430W |
433W |
437W |
|
Qhib Circuit Court voltage (Voc) |
48.54V |
48.68V |
48.82V |
48.96V |
49.10V |
49.25V |
|
Luv Circuit Court tam sim no (lsc) |
11.20A |
11.25A |
11.31A |
11.36A |
11.41A |
11.46A |
|
Max zog Voltage (Vmp) |
39.47V |
39.60V |
39.74V |
39.88V |
40.01V |
40.15V |
|
Max zog tam sim no (lmp) |
10.60A |
10.66A |
10.72A |
10.77A |
10.83A |
10.89A |
Cov yam ntxwv hluav taws xob nrog sib txawv sab nraub qaum zog nce (saib rau 575W pem hauv ntej)
|
Pmax / W |
Voc/V |
Ib/A |
Vmp/V |
Imp / A |
Pmax nce |
|
604 |
52.15 |
14.76 |
43.70 |
13.82 |
5% |
|
633 |
52.15 |
15.47 |
43.70 |
14.48 |
10% |
|
661 |
52.25 |
16.17 |
43.80 |
15.13 |
15% |
|
690 |
52.25 |
16.87 |
43.80 |
15.79 |
20% |
|
719 |
52.25 |
17.58 |
43.80 |
16.45 |
25% |
Kev khiav hauj lwm Parameter
|
Maximum System Voltage |
DC 1500V (IEC / UL) |
|
Ua haujlwm kub |
-40 degree ~ +85 degree |
|
Fais fab tso zis kam rau ua |
0~3% |
|
Maximum Series Fuse |
30A |
|
Maximum Static Load, Pem Hauv Ntej |
5400Pa (112lb/ft²) |
|
Maximum Static Load, Rov qab |
2400Pa (50Ib/ft²) |
|
NOCT |
45 ± 2 degree |
|
Hailstone Test |
25 hli Hailstone ntawm qhov ceev ntawm 23m / s |
|
Chav kawm tiv thaiv |
Chav II |
|
Bifaciality |
60±5% |
Daim ntawv thov Scenario
1. Loj-scale Solar Power Plants:Longi 585W Ob Chav Iav Hnub Ci Vaj Huam Sib Luag yog qhov kev xaiv zoo tshaj plaws rau cov chaw tsim hluav taws xob hnub ci loj vim lawv cov khoom siv hluav taws xob siab thiab ua haujlwm ntev. Lawv muaj kev ua tau zoo heev nyob rau hauv ntau yam huab cua puag thiab muaj lub neej ntev, ua rau lawv muaj txiaj ntsig zoo.
2. Kev lag luam Rooftops:Rau cov lag luam tab tom nrhiav hloov mus rau hnub ci zog, Longi 585W Ob Chav iav panels yog qhov kev xaiv zoo heev. Lawv muaj cov qauv tsim zoo nkauj thiab tuaj yeem ntsia tau yooj yim ntawm kev lag luam ru tsev yam tsis siv ntau qhov chaw. Lawv cov zis hluav taws xob siab txhais tau hais tias cov lag luam tuaj yeem tsim kom muaj lub zog loj, txo lawv txoj kev cia siab rau ntawm daim phiaj thiab txuag nyiaj ntawm cov nqi hluav taws xob.
3.Residential Installations:Cov tswv tsev tab tom nrhiav kev nqis peev rau hnub ci zog tuaj yeem tau txais txiaj ntsig los ntawm kev siv Longi 585W Ob Chav iav hnub ci vaj huam sib luag. Lawv ua tau zoo heev, tso cai rau cov tswv tsev los tsim kom muaj zog ntau dua los ntawm lawv lub ru tsev. Lawv kuj muaj kev tsim qauv zoo nkauj thiab sib xyaw ua ke zoo nrog cov vaj tsev nyob. Tsis tas li ntawd, lawv ob chav iav siv tau zoo dua durability thiab tsis kam rau huab cua, kom ntseeg tau tias lawv yuav tiv taus qhov kev sim ntawm lub sijhawm.
Hom kev sib koom tes
Jingsun yog ib lub chaw muab kev daws teeb meem hnub ci thiab tau tsim kev koom tes nrog ntau lub hnub ci vaj huam sib luag thawj zaug thiab cov tuam txhab inverter xws li Trina Solar, Trina Solar, thiab Longi. Cov kev sib koom tes no yog lub sijhawm tseem ceeb rau Jingshun thaum lawv nthuav dav lub tuam txhab cov khoom lag luam thiab txhim kho nws cov kev sib tw hauv ntiaj teb hnub ci kev lag luam.
Los ntawm cov kev sib koom tes no, Jingsen tau nkag mus rau cov cuab yeej siv thev naus laus zis thiab kev txawj ntse hauv vaj huam sib luag hnub ci thiab kev tsim hluav taws xob inverter. Qhov kev paub no yog qhov tseem ceeb rau kev tsim cov kev daws teeb meem zoo hnub ci kom ua tau raws li kev xav tau ntawm cov neeg siv khoom thoob ntiaj teb. Los ntawm kev koom tes nrog cov thawj coj hauv kev lag luam hnub ci, Jingshun Technology yog qhov chaw zoo los txhim kho nws cov thev naus laus zis thiab kev tsim khoom lag luam.
FAQ
Q: Dab tsi yog Longi 585W Ob Chav iav hnub ci vaj huam sib luag thiab lawv ua haujlwm li cas?
Q: Dab tsi ua rau Longi 585W Ob Chav iav hnub ci vaj huam sib luag zoo dua li lwm hom hnub ci vaj huam sib luag?
Q: Kuv yuav nruab Longi 585W Ob Chav iav hnub ci li cas?
Q: Muaj hluav taws xob ntau npaum li cas Longi 585W Ob Chav iav hnub ci vaj huam sib luag tsim?
Q: Puas yog Longi 585W Ob Chav Iav Hnub Ci Vaj Huam Sib Luag yog qhov kev nqis peev zoo rau kuv cov khoom?
Cov neeg siv tshuaj xyuas
Bellamy Hayes 2024-01-04 22:15:47
Kuv nyuam qhuav yuav ib pawg ntawm Longi 585W Ob Chav iav hnub ci vaj huam sib luag los ntawm Jingsun thiab kuv tsis tuaj yeem zoo siab dua nrog kuv qhov kev txiav txim siab. Jingsun muab kev pabcuam zoo rau cov neeg siv khoom thiab ua rau tag nrho cov txheej txheem yuav khoom. Kuv pom zoo kom lawv rau leej twg hauv kev ua lag luam rau hnub ci vaj huam sib luag.
Caspian Banks 2024-01-10 19: 27:31
Jingsun tau pom zoo rau kuv los ntawm ib tug npoj yaig rau lawv cov nqi zoo ntawm Longi 585W Ob Chav iav hnub ci vaj huam sib luag. Tom qab ua qee qhov kev tshawb fawb thiab tau txais kev sib cuag nrog lawv pab neeg, kuv tuaj yeem hais tias kuv tau zoo siab heev los ntawm qib kev tshaj lij thiab kev txawj ntse.
Jasper Quinn 2024-01-14 21: 36:28
Tsis ntev los no kuv tau ua haujlwm nrog Jingsun los yuav ntau yam ntawm Longi 585W Ob Chav iav hnub ci vaj huam sib luag rau kuv lub lag luam. Kuv yuav tsum hais tias, kuv tau tawg mus rau theem ntawm kev pabcuam cov neeg siv khoom uas lawv tau muab. Pab neeg no tau txais txiaj ntsig zoo thiab muaj kev paub zoo txij thaum pib mus rau qhov kawg, thiab tau mus rau saum toj thiab dhau mus kom ntseeg tau tias kuv cov kev xav tau raug ua tiav.
Magnus Graves 2024-02-09 03:26:34
Jingsun tau tshaj kuv qhov kev cia siab thaum nws los txog rau kev yuav khoom hnub ci. Kuv nyuam qhuav yuav Longi 585W Ob Chav iav hnub ci vaj huam sib luag los ntawm lawv thiab kuv txaus siab heev rau qhov zoo ntawm cov vaj huam sib luag nrog rau cov kev pabcuam.
