Khoom Zoo
Huawei High Current Version 12KW 3-theem Grid Connection PV Inverter yog ib qho khoom siv hluav taws xob zoo tshaj plaws uas muaj ntau yam zoo dua lwm cov inverters hauv khw. Nov yog tsib qhov txiaj ntsig ntawm cov khoom no:
1. Kev ua haujlwm siab:Huawei High Current Version 12KW 3-theem Grid Connection PV Inverter yog tsim los ua kom muaj zog ntau tshaj plaws los ntawm cov hnub ci vaj huam sib luag. Nws tuaj yeem hloov DC hluav taws xob tsim los ntawm lub hnub ci vaj huam sib luag rau hauv AC hluav taws xob nrog kev ua haujlwm txog li 98.6%. Qhov no txhais tau tias ntau lub zog tsim tawm, uas txhais tau tias txo qis nqi hluav taws xob rau cov neeg siv.
2. Muaj kev nyab xeeb thiab ntseeg tau:Huawei High Current Version 12KW 3-theem Grid Connection PV Inverter yog tsim los kom muaj kev nyab xeeb thiab txhim khu kev qha rau cov tswv tsev, cov tsev lag luam, thiab cov tuam txhab siv hluav taws xob zoo ib yam. Nws yog txawm peem rau nrog ib tug ntau yam ntawm kev ruaj ntseg nta xws li surge tiv thaiv, anti-islanding tiv thaiv, thiab overvoltage tiv thaiv, uas lav kev nyab xeeb thiab kev noj qab nyob zoo ntawm nws cov neeg siv.
3. Yooj yim installation thiab tu:Huawei High Current Version 12KW 3-theem Grid Connection PV Inverter yog ib qho yooj yim rau nruab thiab tswj. Nws cov qauv tsim compact txhais tau hais tias nws siv qhov chaw tsawg dua thiab tuaj yeem ntsia tau rau hauv qhov chaw me me. Nws kuj yog ib qho yooj yim los tswj, yuav tsum tau saib xyuas tsawg kawg ntawm cov neeg siv thiab tsis tshua muaj kev soj ntsuam.
4. Smart Grid Compatibility:Huawei High Tam sim no Version 12KW 3-theem Grid Connection PV Inverter yog sib xws nrog ntse daim phiaj technology, ua rau nws yog ib qho khoom zoo rau tsev, lag luam, thiab cov chaw tsim hluav taws xob. Nws cov txheej txheem kev sib txuas lus tso cai rau nws txuas mus rau ntau yam ntawm cov phiaj xwm ntse, muab cov neeg siv nrog cov ntaub ntawv ntawm lub sijhawm tiag tiag uas tuaj yeem siv los ua kom zoo zog tsim hluav taws xob thiab txo cov nqi hluav taws xob.
5. Ib puag ncig phooj ywg:Huawei High Current Version 12KW 3-theem Grid Connection PV Inverter yog ib puag ncig zoo. Nws nquag txhawb kev siv cov khoom siv hluav taws xob tauj dua tshiab, xws li lub hnub ci zog, thiab txo kev cia siab rau cov fossil fuels. Los ntawm kev siv cov inverter no, cov neeg siv tuaj yeem txo lawv cov pa roj carbon hneev taw thiab pab txhawb rau lub ntiaj teb ntsuab.
Zuag qhia tag nrho, Huawei High Current Version 12KW 3-theem Grid Connection PV Inverter yog ib yam khoom zoo heev nrog ntau yam zoo. Nws cov kev ua haujlwm siab, kev nyab xeeb nta, yooj yim installation thiab txij nkawm, ntse daim phiaj sib raug zoo, thiab ib puag ncig tus phooj ywg ua rau nws yog qhov kev xaiv zoo tshaj plaws rau txhua tus neeg nrhiav kev nqis peev hauv lub hnub ci zoo tshaj plaws.
Technical Specification
|
Cov ntaub ntawv Sheet |
SUN 2000 -12KTL-M2 |
SUN 2000 -15KTL-M2 |
SUN 2000 -17KTL-M2 |
SUN 2000 -20KTL-M2 |
|
Kev ua tau zoo |
||||
|
Max. Kev ua tau zoo |
98.50% |
98.65% |
98.65% |
98.65% |
|
European Weighted Efficiency |
98.00% |
98.30% |
98.30% |
98.30% |
|
Tswv yim |
||||
|
Pom zoo max. PV zog |
18, 000 Wp |
22,500 wb |
25,500 wb |
30, 000 Wp |
|
Max. Input voltage |
1,080 V |
|||
|
Kev khiav hauj lwm voltage |
160 V ~ 950 V |
|||
|
Pib-Up Voltage |
200 V |
|||
|
Rated Input Voltage |
600 V |
|||
|
Max. Input Tam sim no Ib MPPT |
27A (ib MPPT) / 18 A (ib qho kev tawm tswv yim) |
|||
|
Max. Short-Circuit Current |
39 A |
|||
|
Tus naj npawb ntawm MPP Trackers |
2 |
|||
|
Max. Number of Inputs |
4 |
|||
|
Tso zis |
||||
|
Daim phiaj kev sib txuas |
Peb theem |
|||
|
Rated tso zis zog |
12,000 W |
15,000 W |
17,000 W |
20,000 W |
|
Max. Pom Lub Hwj Chim |
13,200 VA |
16,500 VA |
18,700 VA |
22, 000 VA |
|
Rated Tso zis Voltage |
220VAC / 380VAC, 230VAC / 400VAC, 3W + N + PE |
|||
|
Rated Ac Grid zaus |
50 Hz / 60 Hz |
|||
|
Max. Tso zis tam sim no |
20 A |
25.2 A |
28.5 A |
33.5 A |
|
Adjustable Power Factor |
{{0}}.8 ua ... 0.8 lagging |
|||
|
Max. Tag nrho Harmonic Distortion |
Tsawg dua lossis sib npaug li 3% |
|||
Cov cuab yeej tiv thaiv
1. DC Overvoltage tiv thaiv
Lub Huawei High Tam sim no Version 12KW 3-theem Grid Connection PV Inverter yog nruab nrog siab tshaj DC overvoltage tiv thaiv. Cov yam ntxwv no ua kom ntseeg tau tias lub inverter tswj kev ua haujlwm ruaj khov thiab nyab xeeb txawm tias cov khoom siv hluav taws xob ntau tshaj qhov kev tso cai. Qhov no ua kom ob qho tib si kev nyab xeeb ntawm inverter thiab cov khoom siv txuas nrog thiab cov khoom siv hluav taws xob siab tshaj plaws, ua rau nws yog qhov kev xaiv zoo tshaj plaws rau kev teeb tsa lub hnub ci ntawm txhua qhov loj.
2. DC Surge Protection
Lwm qhov tseem ceeb ntawm qhov inverter no yog DC surge tiv thaiv. Cov cuab yeej tiv thaiv no pab txhawm rau tshem tawm cov surges tam sim ntawd lossis voltage spikes uas yuav tshwm sim thaum lub sijhawm ua haujlwm, lav tias lub inverter thiab cov cuab yeej txuas nrog raug tiv thaiv los ntawm ib qho hluav taws xob sab nraud.
3. AC Overcurrent Protection
Lub inverter los nrog advanced AC overcurrent tiv thaiv uas ua kom ntseeg tau tias lub inverter tsis tau overloaded txawm hais tias cov khoom siv txuas nrog muaj kev kub ntxhov. Cov cuab yeej no pab tiv thaiv lub inverter thiab ua kom nws khiav zoo.
4. AC Surge Protection
Lub inverter los nruab nrog AC surge tiv thaiv, uas ua haujlwm los tiv thaiv lub inverter thiab tag nrho cov khoom siv txuas nrog los ntawm ib qho surges lossis voltage spikes hauv AC fais fab mov. Cov cuab yeej tiv thaiv no ua kom ntseeg tau tias lub inverter lub neej yog nce thiab nws ua haujlwm zoo.
5. Kev tiv thaiv hauv av tam sim no
Thaum kawg, Huawei High Current Version 12KW 3-theem Grid Connection PV Inverter kuj tau nruab nrog kev tiv thaiv hauv av tam sim no, uas ua kom ntseeg tau tias txhua qhov kev ua txhaum hauv av lossis tam sim no xau raug kuaj pom thiab kho tam sim. Qhov no feature pab tiv thaiv lub inverter thiab xyuas kom meej tias nws ua hauj lwm yam xyuam xim thiab cia siab rau lub sij hawm.
Cov ntaub ntawv dav dav
|
Kev khiav hauj lwm qhov kub thiab txias |
-25 ~ +60 degree ({2}} degree F ~ 140 degree F) |
|
txheeb ze humidity |
0 % RH ~ 100% RH |
|
Max. Ua haujlwm Altitude |
0 - 4, 000 m (13,123 ft.) (Derating saum 2000 m) |
|
Txias |
Ntuj Convection |
|
Zaub |
LED qhov taw qhia; Integrated WLAN + Fusion Solar App |
|
Kev sib txuas lus |
RS485; WLAN/Ethernet ntawm Smart Dongle-WLAN-FE (Yeem) 4G / 3G / 2G ntawm Smart Dongle-4G (Yeem) |
|
Qhov hnyav (nrog Mounting phaj) |
25 kg ib |
|
Dimensions (W x H x D) (nrog rau mounting phaj) |
525 x 470 x 262 mm (20.7 x 18.5 x 10.3 nti) |
|
Qib Kev Tiv Thaiv |
IP65 |
|
Kev siv hluav taws xob hmo ntuj |
< 5.5W |
|
DC MBUS Compatible Optimizer |
SUN2000-450WP,SUN2000-450W-P2,SUN2000-600WP |
|
Kev nyab xeeb |
EN/IEC 62109-1, EN/IEC 62109-2 |
|
Grid Connection Standards |
G98, G99, EN 50549, CEI 0-21, CEI 0-16, VDE-AR-N-4105, VDE-AR-N-4110, AS 4777.2, C10/11, ABNT, VFR 2019, RD 1699, RD 661, PO 12.3, TOR D4, IEC61727, IEC62116, DEWA |
Kev koom tes hom
Jingsun Solar Co., Ltd., yog lub tuam txhab ua lag luam ntawm cov khoom siv hnub ci, tau tsim kev koom tes ntev thiab tob nrog ntau lub tuam txhab hnub ci inverter. Cov kev sib koom tes no tau ua rau Jingsun nthuav dav thiab nthuav dav nws cov khoom lag luam, muab cov neeg siv khoom nrog ntau qhov kev daws teeb meem zoo hnub ci rau lawv lub tsev lossis kev lag luam.
Los ntawm cov kev sib koom tes no, Jingsun tau nkag mus rau cov thev naus laus zis thiab kev txawj ntse, tso cai rau lub tuam txhab txhim kho kev ua haujlwm thiab kev ua haujlwm ntawm nws cov khoom hnub ci. Qhov no tau ua rau Jingsun tuaj yeem muab cov neeg siv khoom tshiab tshiab thiab kev nce qib hauv kev siv hluav taws xob hnub ci.
FAQ
Q: Huawei High Current Version 12KW 3-theem Grid Connection PV Inverter yog dab tsi?
Q: Dab tsi yog cov yam ntxwv ntawm Huawei High Current Version 12KW 3-theem Grid Connection PV Inverter?
Q: Huawei High Current Version 12KW 3-theem Grid Connection PV Inverter ua haujlwm li cas?
Q: Dab tsi yog cov txiaj ntsig ntawm kev siv Huawei High Current Version 12KW 3-theem Grid Connection PV Inverter?
Q: Kuv yuav nruab thiab tswj hwm Huawei High Current Version 12KW 3-theem Grid Connection PV Inverter li cas?
Cim npe nrov: huawei sun2000 12ktl m2, Tuam Tshoj huawei sun2000 12ktl m2 manufacturers, lwm tus neeg, Hoobkas
